| PARAMETER | CENTRO 100 50 HZ | MEASUREMENT UNIT | |
|---|---|---|---|
| Voltage | 230 | V | |
| Phase | 1 | ˜ | |
| Frequency | 50 | Hz | |
| Power | 80 | W | |
| Current | 0.34 | A | |
| Air capacity | 69 | l/s | |
| Air capacity | 250 | m³/h | |
| Sound pressure level at 3 m distance | 40 | dB? | |
| Max. operating temperature | -25...+50 | °? | |
| RPM | 2820 | min-1 | |
| EC motor | no | - | |
| Ingress protection rating | IPX4 | - | |
| Motor IP rating | IP44 | - | |
| ErP | 2016, 2018 | - | |
| Casing material | plastic | - | |
| Outdoor mounting | no | - | |
| Sound-insulated casing | no | - | |
| Air duct | for round air ducts | - | |
| Connection diameter | 100 | mm | |
| Design | centrifugal | - | |
| Type | Exhaust , Supply | - | |
| SEC class | C | - | |
| Weight | 2.08 | kg | |
| Mounting | Inline | - |
